Cisco WAN Automation Engine 6.3.1 with 8 Nodes v1 now available!

[lamarsh]

Overview

The Cisco WAN Automation Engine (WAE) is a powerful, flexible, software-defined networking (SDN) platform. It abstracts and simplifies your WAN environment while making it fully open and programmable. It is a network modeling technology that enables real-time analysis of traffic needs and placement in complex WAN topologies.

Check it out here: Cisco WAN Automation Engine 6.3.1 with 8 Nodes v1

Scenarios

• Scenario 1: Offline Planning with MATE Design
• Scenario 2: Bandwidth on Demand
• Scenario 3: Tunnel Balancer
• Scenario 4: Tunnel Builder
• Scenario 5: Bandwidth Calendaring
• Scenario 6: WAE API and Tunnel Split/Merge
• Scenario 7: Segment Routing Tunnel Builder
• Scenario 8: Tunnel Builder with NSO as Deployer
• Scenario 9: WAE API with NSO as Deployer

Requirements

Required	Optional
Laptop	Cisco AnyConnect

Components

• Cisco BGP-LS technology
• Cisco WAE 6.3.1 SDN Server
• TraGenSer, traffic generator
• Cisco IOS XRVR 6.0.0
• Cisco PCE and PCEP Technology
• CentOS 7
• Docker
• Nginx
• VIRL

Features

Cisco WAE	State-of-the-art network and traffic modeling technology. Intuitive interface for creating flows, tunnels, and demands. Cloud SDN application suite with advanced PCE.
Virtual Internet Routing Lab (VIRL)	Multi-purpose network virtualization platform. Provides an easy way to build, configure, and test new or existing network topologies.

Topology
