Unicast TEP IP in Multi Pod?

[suneq]

Hi,

I am trying to add a 3rd Pod into our current Multi Pod configuration version 5.2(x)

In the Wizard 4.External TEP, I see the "Unicast TEP IP" which was not there in the version 4.2(x) when we installed the Fabric.

I have not found much information about this unicast TEP IP and how I can verify the current unicast TEP IP of the Pod 1 & 2.

I don't want to make any mistake by entering the wrong value and then break the current Fabric

Thanks a lot for your help.

[M02@rt37]

Hello @suneq

The Unicast TEP IP field is optional. Cisco APIC automatically configures the unicast TEP IP address when you enter the data plane TEP IP address.

Reference: https://www.cisco.com/c/en/us/td/docs/switches/datacenter/aci/apic/sw/4-x/L3-configuration/Cisco-APIC-Layer-3-Networking-Configuration-Guide-401/Cisco-APIC-Layer-3-Networking-Configuration-Guide-401_chapter_010110.html
