Hello,
Currently I am attempting to configure my Nexus 9332C to use a breakout cable with the following commands:
int breakout module 1 port 21-23 map 10g-4x
However, I am receiving "Error: Breakout map not supported for slot 1 port 21" when I attempt to run the configuration command. Am I missing something beyond this? The interface shows the cable is properly placed so it's definitely something on my end in the configuration from my understanding.
Here is the output of show eth 1/21 transceiver:
Ethernet1/21
transceiver is present
type is QSFP-40G-SR4
name is FINISAR
part number is FTL410QE2C-G1
revision is A
serial number is GQ305AT
nominal bitrate is 10300 MBit/sec per channel
Link length supported for 50/125um OM3 fiber is 100 m
cisco id is 13
cisco extended id number is 16
Please let me know if you need the output of any other commands. Thanks!
