%DC-4-FILE_OPEN_WARNING

esalonia
Level 1
Level 1
I recently upgraded a few 2960 switches to 15.0(1)SE, and while they are
working fine, I did notice a strange syslog message upon boot-up that wasn't
previously there. The message is as follows:

*Mar  1 00:00:39.535: %DC-4-FILE_OPEN_WARNING: Not able to open
flash:/dc_profile_dir/dc_default_profiles.txt
*Mar  1 00:00:39.535: %DC-6-DEFAULT_INIT_INFO: Default Profiles DB not
loaded.

I did some cursory searching via google but nothing useful presented itself.
Does anyone know what this is for?

Thank you in advance,

Ed
10 Replies 10

Ivan Krimmel
Level 7
Level 7

Hi Ed,

this one is known cosmetic bug and doesn't have operatoin impact. Will be fixed once 15th gets matured.

HTH,

Ivan.

Thanks for the info. I had a feeling it was only cosmetic.

Can you tell me what it's for though?

- Ed

Ed,

The error message implies the switch has not loaded the default profile file on the flash. I am not sure where this profile arises though.

Hope that clarifies,

Ivan.


Right. I was just curious about what the "profile" is for.

Thanks

Ivan,

Is there a bug ID associated with this that I can look up?

Do you know what this "profile" is for?

Edward,

since the bug is cosmetic in nature it has been decided not to post it on CCO, rather to fix it in the upcoming releases. I frankly am not sure what the profile stands for, because I have little to know exposure to that type of platforms.

Cheers,

Ivan.

I am sitting here a 'few' years later just upgraded a:

- WS-C2960-24TT-L running SW Image C2960-LANBASEK9-M IOS version 15.0(2)SE11 (c2960-lanbasek9-mz.150-2.SE11.bin)



I still see the following while connected at console after IOS boot:

-  %DC-4-FILE_OPEN_WARNING: Not able to open flash:/dc_profile_dir/dc_default_profiles.txt

- %DC-6-DEFAULT_INIT_INFO: Default Profiles DB not loaded.



Just to note, at this time this version is the latest available from the CISCO software download page.



Workaround for the Catalyst 2960 DC-4-FILE_OPEN_WARNING error

The IOS is looking for the "dc_default_profiles.txt" file in the flash directory for a folder named "dc_profile_dir" and failing to find it, creates the error message. The "dc_default_profiles.txt" file is located under the IOS directory (flash:/c2960-lanbasek9-mz.150-1.SE). Cisco programmers will need to correct the installation & lookup of the file. Until then, here's the workaround.

Workaround steps:
1. Create the dc_profile_dir in the flash directory
#mkdir flash:/dc_profile_dir

2. Change path to the IOS directory
#cd flash:/c2960-lanbasek9-mz.150-1.SE

3. Copy the "dc_default_profiles.txt" file to the proper directory
#copy flash:/c2960-lanbasek9-mz.150-1.SE/dc_default_profiles.txt flash:/dc_profile_dir/dc_default_profiles.txt

4. Verify file
#cd
#cd flash:/dc_profile_dir
#dir

You should see the file in the directory:
570  -rwx       61977  Feb 28 1993 19:16:53 -05:00  dc_default_profiles.txt

The IOS now will locate the file and not return any more error messages when the switch is rebooted.

Attached is the dc_default_profiles.txt if you are interested in viewing it.

- Ted

Running c3750e-universalk9-mz.152-2.E.bin here and seeing:



Mar 29 21:03:10.291 EST: %DC-3-MAX_OUI_EXCEEDED: total OUI found=%d  exceeds the max supported=%d .
Mar 29 21:03:10.291 EST: %DC-3-OUI_INIT_FAIL: OUI Table initialization failed for flash:/dc_profile_dir/dc_default_profiles.txt

How can I edit flash:/dc_profile_dir/dc_default_profiles.txt so that auto smartports wil work with this version?

All I see are the built-ins:

980-chester-switch#show macro auto monitor type
Mar 29 21:05:29.425 EST: %SYS-5-CONFIG_I: Configured from console by cisco on vty0 (172.26.29.85)
  Valid         Type       Profile Name                         min Conf   ID
===========  =========  ==================                      ========  ====
  Valid        Built-in     Cisco-Device                              10        0
  Valid        Built-in     Cisco-Router                              10        1
  Valid        Built-in     Router                                    10        2
  Valid        Built-in     Cisco-IP-Camera                           10        3
  Valid        Built-in     Cisco-IP-Camera-2xxx                      30        4
  Valid        Built-in     Cisco-IP-Camera-2421                      50        5
  Valid        Built-in     Cisco-IP-Camera-2500                      50        6
  Valid        Built-in     Cisco-IP-Camera-2520                      50        7
  Valid        Built-in     Cisco-IP-Camera-2530                      50        8
  Valid        Built-in     Cisco-IP-Camera-4xxx                      50        9
  Valid        Built-in     Cisco-Transparent-Bridge                  8         10
  Valid        Built-in     Transparent-Bridge                        8         11
  Valid        Built-in     Cisco-Source-Bridge                       10        12
  Valid        Built-in     Cisco-Switch                              10        13
  Valid        Built-in     Cisco-IP-Phone                            20        14
  Valid        Built-in     IP-Phone                                  20        15
  Valid        Built-in     Cisco-DMP                                 10        16
  Valid        Built-in     Cisco-DMP-4305G                           70        17
  Valid        Built-in     Cisco-DMP-4310G                           70        18
  Valid        Built-in     Cisco-DMP-4400G                           70        19
  Valid        Built-in     Cisco-WLC-2100-Series                     40        20
  Valid        Built-in     Cisco-Access-Point                        10        21
  Valid        Built-in     Cisco-AIR-LAP                             30        22
  Valid        Built-in     Cisco-AIR-AP                              30        23
  Valid        Built-in     Linksys-Device                            20        24



arun
Level 1
Level 1

how to rectify this issue kindly mail me arun@tglobalin.com
