BGP Load Balancing and CEF

mautez_mah
Level 1
Level 1

Dear Gents

Why should Enable Cef if we need to perform BGP multipath , what if it is not enabled and router is working on Fast or process switching, what issue may cause ,

future more

can we apply BGP Load Balancing per Packet , or per destination , ( inbound and outbound )
only Scenario I am sure about it is load sharing ( per subnet )

5 Replies 5

balaji.bandi
Hall of Fame
Hall of Fame

Load balancing over the multipaths is performed by CEF. CEF load balancing is configured on a per-packet round robin or on a per session (source and destination pair) basis.



below guide help more understanding :



https://www.cisco.com/c/en/us/td/docs/ios/12_2sx/feature/guide/fsxeibmp.html

BB

***** Rate All Helpful Responses *****

How to Ask The Cisco Community for Help

Joseph W. Doherty
Hall of Fame
Hall of Fame

"Why should Enable Cef if we need to perform BGP multipath , what if it is not enabled and router is working on Fast or process switching, what issue may cause ,"

What might be caused, and likely will, without CEF enabled, is much slower packet routing, especially of the first packet of a flow.  It might also increase the work load on the device.

"can we apply BGP Load Balancing per Packet , or per destination , ( inbound and outbound )
only Scenario I am sure about it is load sharing ( per subnet ) "

First, load balancing would be outbound, not inbound.  Second, (as already noted by @balaji.bandi), CEF load balancing is per packet, per flow, which often tends to very nicely/well balance egress link loads.  However, although in theory, IP doesn't guarantee flow packet sequence, which TCP does, many applications not using TCP are "disturbed" by flow packet re-sequencing, and even TCP, may initially consider packets arriving out of sequence as having been "lost" in transit, which may invoke TCP's flow rate back-off and/or retransmission of "lost" packets.  So, avoiding packet by packet LB is generally highly recommended!

many thanks
@balaji.bandi many thanks
@Joseph W. Doherty  so If the router ( assuming ) is not using CEF we can do Load-sharing for BGP , right ?
and as you told me we can't guarantee traffic inbound so can we use per destination or it will be same issue
so we can only rely on per subnet ?

CEF did (not sure about all current implementations) allow/support per-packet LB.  Otherwise, it's per flow, although don't recall if it LBs flows, to same prefix.
