CUBE SIP-TLS/SRTP with ITSP

[Daniel Lucas]

Anyone successfully deploy SIP w/ TLS/SRTP with an ITSP?

Doesn't seem like it's something that is done very often - was curious if anyone has actually successfully deployed it.

-Thanks

[R0g22]

What is the issue that you are facing ?

[Daniel Lucas]

Appears to be a certificate issue - we are getting a TLS Fatal Alert 48 - Unknown CA from the carrier when we are the server (calls/sip connection is inbound w/ respect to our CUBE).

Carrier is requesting we disable mutual authentication; which I don't believe is a configurable option on the 4K, and also shouldn't be causing this problem.

Just seems like the lack of documentation/technical support for doing this implies that it is very rarely done. Was curios if anyone has successfully implemented it, how they went about it, and what issues they ran into.

-Thanks

[R0g22]

So your outbound calls work fine ? Is there a log that you can share which highlights the error ? This is definitely not something that rare. There are deployments that use SIP TLS/SRTP with ITSP.

[Daniel Lucas]

Yes, outbound calls work - TLS Handshake completes (we receive certificate from carrier, authenticate it, and begin encrypted session).

Below is screenshot of packet capture when our CUBE is acting as the server:

[R0g22]

Ok. From the snippet, I see "Server Hello", CUBE sending it's digital certificate and then requesting the certificate of the client which would be your ITSP. This is correct. The client cert request is optional but it is not illegal.
Who is sending the "Fatal Error" ? I can't see the IP addresses in the snippet.

[Daniel Lucas]

Thanks for the response,

The fatal error is coming from the carrier.

The mutual authentication is something that the carrier asked about - is this a configurable option on the CUBE (IOSXE 16.5.1b)? A document I found from 2008 said that the CUBE always performed mutual authentication when acting as the server; wasn't sure if maybe this has changed since then. I found an old config guide for the ASR1K which said that per-interface tls mutual authentication for SIP was added in XE version 2.6 - but this command has either been removed since then, or isn't available on the 4K.

-Thanks

[R0g22]

That's right. CUBE will always do mutual authentication.
The interface mutual-authentication applies to CUBE-SP and not enterprise which is what you are using.
https://www.cisco.com/c/en/us/td/docs/routers/asr1000/configuration/guide/sbcu/2_xe/sbcu_2_xe_book/sbc_adj.html#pgfId-1202186

[Daniel Lucas]

Ok thanks for the info,

We ended up getting this working, and wasn't related to mutual authentication - turns out the ITSP needed to import our entire certificate chain, and not just our identity cert + singing CA certificate. Why they even needed to install our identity certificate seems a little silly since by installing/trusting our singing CA certificate they should be able to validate our identity certificate using that when we send our identity cert as part of the TLS handshake. I guess different applications go about it a little different than others.

-Thanks
