04-23-2020 07:08 AM
Hello,
I've been given an ASR903 to configure for use on a testbed. However when I first booted it up, it says:
no valid BOOT image found
Final autoboot attempt from default boot device....
Warning: filesystem is not clean
Warning: filesystem is not clean
Located tracelogs.332
Image size 0 inode num 12, bks cnt 0 blk size 8*512
Boot image size = 0 (0x0) bytes
Warning: filesystem is not clean
Located ASR-903_FOX1729P00T.lic
Image size 1139 inode num 13, bks cnt 1 blk size 8*512
#
Boot image size = 1139 (0x473) bytes
Unknown image structure
boot: cannot determine first file name on device "bootflash:/"
autoboot: boot failed, restarting
Then the system starts up in ROMmon mode. I did some googling and tried to boot off of a usb which is the following:
rommon 14 > boot usb0:asr900rsp2-universalk9_npe.03.18.01.S.156-2.S1-std.bin
Checking USB devices..
USB EHCI 1.00
scanning USB bus for devices..
2 USB device(s) found
Scanning bus for storage devices...
USB mass storage device detected
1 storage device(s) found
Located asr900rsp2-universalk9_npe.03.18.01.S.156-2.S1-std.bin, start cluster is 3
#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.#.
Image loaded
Boot image size = 312800260 (0x12a4f404) bytes
Unknown image structure
boot: error executing "boot usb0:asr900rsp2-universalk9_npe.03.18.01.S.156-2.S1-std.bin"
I've been googling different ways to upload the IOS onto the device all day and I'm at my wit's end. Any help is much appreciated.
Also I obtained the .bin file from another testbed ASR903 in a building that I don't have 24/7 access to.
Thanks,
Adam
Solved! Go to Solution.
04-29-2020 03:19 AM
04-23-2020 03:14 PM
04-24-2020 03:21 AM
04-24-2020 03:56 AM - edited 04-24-2020 03:58 AM
While in ROMMON, try this:
copy usb0:asr900rsp2-universalk9_npe.03.18.01.S.156-2.S1-std.bin bootflash:
After the copying has been completed, then do this:
boot bootflash:asr900rsp2-universalk9_npe.03.18.01.S.156-2.S1-std.bin
04-24-2020 04:02 AM
04-24-2020 06:25 AM
How about this:
emergency-install usb0:asr900rsp2-universalk9_npe.03.18.01.S.156-2.S1-std.bin
04-24-2020 06:33 AM
04-24-2020 05:41 PM
04-25-2020 01:58 AM - edited 04-25-2020 02:04 AM
rommon 14 > ?
alias set and display aliases command
boot boot up an external process
break set/show/clear the breakpoint
confreg configuration register utility
context display the context of a loaded image
cookie display contents of cookie PROM in hex
dev list the device table
dir list files in file system
eject safely remove the harware
dis display instruction stream
frame print out a selected stack frame
help monitor builtin command help
history monitor command history
meminfo main memory information
repeat repeat a monitor command
reset system reset
set display the monitor variables
showmon display currently selected ROM monitor
stack produce a stack trace
sync write monitor environment to NVRAM
sysret print out info from last system return
unalias unset an alias
unset unset a monitor variable
set_rommon_upgrade set iocpld bits for upgrade
rommon 15 >
04-25-2020 03:13 AM
04-25-2020 03:51 AM
I booted up the router to try input the set command but now it is stuck on this screen. This output is straight from powering on.
04-29-2020 02:29 AM
I have fixed the other issue by changing the baud rate, here is the result for the set command.
rommon 1 > set PS1=rommon ! > LICENSE_BOOT_LEVEL=metroaggrservices,all:ASR-903; MCP_STARTUP_TRACEFLAGS=00000000:00000000 RET_2_RTS= LICENSE_ACTIVE_LEVEL=metroaggrservices,all:ASR-903; CONFIG_FILE= BOOTLDR= RANDOM_NUM=562010964 BSI=0 RET_2_RCALTS= BOOT= ?=1 rommon 2 >
04-29-2020 03:19 AM
04-29-2020 05:36 AM
That's fixed it!! You were completely right, the RSP I had was ASR903-RSP1. I have downloaded the correct IOS and booted from the usb in rommon mode and it works! Thank you very much!
04-29-2020 05:51 PM
