Hey!
I am learning Cisco CUBE and various functions before we install in our production environment.
I have managed to setup two PBX, two CUBE and two IP phone. And i can seup calls between the phones with matching on called-number and destionation-pattern (as configuration example below).
But i would like to match the destination on URI, for example 172.16.10.30 (My PBX2)
How do i achieve that? because when i debug and looks at the SIP message header the "TO" field is my default gateway.
INVITE sip:223344@192.168.50.21:5060 SIP/2.0
Via: SIP/2.0/UDP 192.168.50.1:5060;branch=z9hG4bK811BE5
Remote-Party-ID: "MicroSIP1" <sip:555444@192.168.50.1>;party=calling;screen=no;privacy=off
From: "MicroSIP1" <sip:555444@192.168.50.1>;tag=5279030-235E
To: <sip:223344@192.168.50.21>
Date: Wed, 16 Mar 2022 12:50:12 GMT
Call-ID: 73F6FB56-A45E11EC-88C2BE8A-296F00AF@192.168.50.1
Supported: 100rel,timer,resource-priority,replaces,sdp-anat
Min-SE: 1800
Cisco-Guid: 1945535980-2757628396-2294070922-0695140527
User-Agent: Cisco-SIPGateway/IOS-17.3.4a
Allow: INVITE, OPTIONS, BYE, CANCEL, ACK, PRACK, UPDATE, REFER, SUBSCRIBE, NOTIFY, INFO, REGISTER
CSeq: 101 INVITE
Timestamp: 1647435012
Contact: <sip:555444@192.168.50.1:5060>
Expires: 180
Allow-Events: telephone-event
Max-Forwards: 69
Session-ID: df81484d65445ab7bb619e966f2b287d;remote=00000000000000000000000000000000
Session-Expires: 1800
Content-Type: application/sdp
Content-Disposition: session;handling=required
Content-Length: 309
Router 1.
dial-peer voice 100 voip
description inbound LAN
session protocol sipv2
incoming called-number 55....
voice-class sip bind control source-interface GigabitEthernet2
voice-class sip bind media source-interface GigabitEthernet2
codec transparent
no vad
!
dial-peer voice 101 voip
description outbound LAN
destination-pattern 223344
session protocol sipv2
session target ipv4:192.168.10.20
voice-class sip bind control source-interface GigabitEthernet2
voice-class sip bind media source-interface GigabitEthernet2
codec transparent
no vad
!
dial-peer voice 200 voip
description outbound WAN
destination-pattern 55....
session protocol sipv2
session target ipv4:192.168.50.1
voice-class sip bind control source-interface GigabitEthernet1
voice-class sip bind media source-interface GigabitEthernet1
codec transparent
no vad
!
dial-peer voice 201 voip
session protocol sipv2
incoming uri from 1000
voice-class sip bind control source-interface GigabitEthernet1
voice-class sip bind media source-interface GigabitEthernet1
codec transparent
no vad
!
03-23-2022 11:10 AM
Have a look at this great document for details on dial peer configuration.
In general my recommendation would be to use information in the via header for inbound dial peer match.
03-25-2022 09:36 AM
Based on your shared information this would be my suggested configuration for router 1.
Router 1 voice class e164-pattern-map 1 description E164 Pattern Map for called number to PBX1 e164 22.... ! voice class e164-pattern-map 2 description E164 Pattern Map for called number to PBX2 e164 55.... ! voice class uri PBX1 sip host ipv4:192.168.10.20 ! voice class uri PBX2 sip host ipv4:192.168.50.1 ! voice class codec 1 codec preference 1 g711alaw codec preference 2 g711ulaw ! dial-peer voice 100 voip description *** Inbound LAN from PBX1 *** session protocol sipv2 incoming uri via PBX1 voice-class codec 1 voice-class sip bind control source-interface GigabitEthernet2 voice-class sip bind media source-interface GigabitEthernet2 no vad ! dial-peer voice 101 voip description *** Outbound LAN to PBX1 *** destination e164-pattern-map 1 session protocol sipv2 session target ipv4:192.168.10.20 voice-class codec 1 voice-class sip options-keepalive voice-class sip bind control source-interface GigabitEthernet2 voice-class sip bind media source-interface GigabitEthernet2 no vad ! dial-peer voice 200 voip description *** Inbound WAN from PBX2 *** session protocol sipv2 incoming uri via PBX2 voice-class codec 1 voice-class sip bind control source-interface GigabitEthernet1 voice-class sip bind media source-interface GigabitEthernet1 no vad ! dial-peer voice 201 voip description *** Outbound WAN to PBX2 *** destination e164-pattern-map 2 session protocol sipv2 session target ipv4:192.168.50.1 voice-class codec 1 voice-class sip options-keepalive voice-class sip bind control source-interface GigabitEthernet1 voice-class sip bind media source-interface GigabitEthernet1 no vad
